How it works

Private Payments uses a combination of ZK proofs and MPC-held secret shares to keep balances and transfer amounts private while settling on a public chain. This page describes each component and walks through a deposit end-to-end.

Components​

Client. The application or wallet initiating transactions using the Merces SDK. It generates ZK proofs locally and holds the private key — all cryptographic operations happen on the client before any network call is made.

Gateway. The offchain coordinator that receives client requests over WebSocket, submits transactions to the Merces contract, and returns the final transaction hash once the MPC network has finalised the balance update.

Id Registry. The registry for mapping wallet addresses to indices in the Oblivious Merkle Tree. Client registers a commitment to their wallet and gets a inclusion proof needed for private transactions.

MPC network. A committee of three operators that hold balances as additive secret shares. No single operator ever sees a plaintext balance or transfer amount. The network reads queued actions from the contract, runs an MPC protocol to update shares, generates a proof of correct execution, and calls back into the contract.

Merces contract. Stores balance commitments onchain, verifies the client's Groth16 proof when an action is submitted, enqueues the action for the MPC network, and verifies the MPC network's proof when the balance update is finalised.


Transaction flow​

A deposit moves ERC-20 tokens from a user's public wallet into their private Merces account. The sequence below shows a privateDeposit — the confidentialDeposit path is identical except the sender address remains visible onchain.

Step by step​

1. Proof generation (client-side). The client splits the deposit amount into three additive secret shares, encrypts each to the corresponding MPC operator's public key, and generates a Groth16 ZK proof that the shares are consistent with the committed amount. This step is fully local — no network call is made yet.

2. Submission. The client sends the proof and ciphertexts to the gateway over WebSocket. The gateway constructs and submits the deposit transaction to the Merces contract.

3. Onchain verification. The contract verifies the Groth16 proof, records the new commitment, and emits an event that signals the MPC network to pick up the queued action.

4. MPC balance update. The three operators jointly decrypt the ciphertexts to recover the deposit amount, update the user's secret-shared balance, and generate a second Groth16 proof that the update is correct. They call processMPC() on the contract with the proof and updated commitments.

5. Finalisation. The contract verifies the MPC proof and commits the new balance state. The transaction hash is returned through the gateway to the client.

Withdrawals and transfers follow the same structure. For transfers, the MPC network additionally updates the receiver's balance shares in the same round.
